BAG FILTER

small logo

POLYESTER(P.E)









Material

POLYESTER

Weight (g/m2)

550 ± 20

Thickness (mm)

2 ± 0.2

Ventilation (cm3/cm2sec)

16 ± 2

Tensile Strength, length (kg)

160 ± 20

Tensile Strength, width (kg)

180 ± 20

Elongation, length (%)

35

Elongation, width (%)

35

Bursting strength (kg/m2)

50 ± 10

Effective temperature (°C)

130

Temperature (°C)

130

Limit temperature (°C)

130

Acid-resistant

FAIR

Alkali-resistance

FAIR

POLYESTER + CARBON(PE+SUS)









Material

POLYESTER

Weight (g/m2)

600 ± 20

Thickness (mm)

2 ± 0.1

Ventilation (cm3/cm2sec)

15 ± 2

Tensile Strength, length (kg)

160 ± 20

Tensile Strength, width (kg)

180 ± 20

Elongation, length (%)

35

Elongation, width (%)

35

Bursting strength (kg/m2)

60 ± 10

Effective temperature (°C)

130

Temperature (°C)

130

Limit temperature (°C)

130

Acid-resistant

FAIR

Alkali-resistance

FAIR

HOMO ACRYLIC









Material

HOMO ACRYLIC

Weight (g/m2)

550 ± 20

Thickness (mm)

2 ± 0.2

Ventilation (cm3/cm2sec)

18 ± 2

Tensile Strength, length (kg)

100 ± 20

Tensile Strength, width (kg)

120 ± 20

Elongation, length (%)

50

Elongation, width (%)

50

Bursting strength (kg/m2)

40 ± 10

Effective temperature (°C)

125

Temperature (°C)

125

Limit temperature (°C)

130

Acid-resistant

GOOD

Alkali-resistance

FAIR

NOMEX (COMEX)









Material

ARAMIDE

Weight (g/m2)

550 ± 20

Thickness (mm)

2 ± 0.2

Ventilation (cm3/cm2sec)

15 ± 2

Tensile Strength, length (kg)

140 ± 20

Tensile Strength, width (kg)

160 ± 20

Elongation, length (%)

35

Elongation, width (%)

35

Bursting strength (kg/m2)

50 ± 10

Effective temperature (°C)

180

Temperature (°C)

200

Limit temperature (°C)

230

Acid-resistant

FAIR

Alkali-resistance

GOOD

RYTON (P.P.S, Poly phenylene sulfide)









Material

P.P.S

Weight (g/m2)

550 ± 20

Thickness (mm)

1.9 ± 2

Ventilation (cm3/cm2sec)

15 ± 2

Tensile Strength, length (kg)

110 ± 20

Tensile Strength, width (kg)

120 ± 20

Elongation, length (%)

55

Elongation, width (%)

50

Bursting strength (kg/m2)

40 ± 20

Effective temperature (°C)

170

Temperature (°C)

180

Limit temperature (°C)

200

Acid-resistant

EXCELLENT

Alkali-resistance

EXCELLENT

P84









Material

POLYIMIDE

Weight (g/m2)

550 ± 20

Thickness (mm)

2.3 ± 2.3

Ventilation (cm3/cm2sec)

16 ± 2

Tensile Strength, length (kg)

100 ± 20

Tensile Strength, width (kg)

100 ± 20

Elongation, length (%)

60

Elongation, width (%)

60

Bursting strength (kg/m2)

50 ± 10

Effective temperature (°C)

260

Temperature (°C)

260

Limit temperature (°C)

280

Acid-resistant

VERY GOOD

Alkali-resistance

FAIR

GLASS









Material

GLASS FIBER

Weight (g/m2)

750 ± 20

Thickness (mm)

1.1 ± 0.2

Ventilation (cm3/cm2sec)

16 ± 1

Tensile Strength, length (kg)

250 ̻

Tensile Strength, width (kg)

200 ̻

Elongation, length (%)

15

Elongation, width (%)

15

Bursting strength (kg/m2)

70 ± 10

Effective temperature (°C)

240

Temperature (°C)

260

Limit temperature (°C)

290

Acid-resistant

VERY GOOD

Alkali-resistance

FAIR

TEFLON (PTFE-poly tetra flour ethylene)









Material

P.T.F.E

Weight (g/m2)

750 ± 30

Thickness (mm)

1.2 ± 0.1

Ventilation (cm3/cm2sec)

20 ± 2

Tensile Strength, length (kg)

100 ± 20

Tensile Strength, width (kg)

120 ± 20

Elongation, length (%)

50

Elongation, width (%)

50

Bursting strength (kg/m2)

50 ± 10

Effective temperature (°C)

250

Temperature (°C)

260

Limit temperature (°C)

290

Acid-resistant

EXCELLENT

Alkali-resistance

EXCELLENT

POLYESTER









Material

P.E

Weight (g/m2)

320 ± 10

Thickness (mm)

0.8

Ventilation (cm3/cm2sec)

18

Tensile Strength, length (kg)

160 ± 20

Tensile Strength, width (kg)

160 ± 20

Elongation, length (%)

40

Elongation, width (%)

40

Bursting strength (kg/m2)

50 ± 10

Effective temperature (°C)

130

Temperature (°C)

130

Limit temperature (°C)

130

Acid-resistant

FAIR

Alkali-resistance

FAIR
